Taking our proven High Pivot Trifecta suspension system and One Ride geometry and turning it up to eleven, the 154mm travel Dreadnought represents a bike for the risk-takers and senders out there. Boasting an unmatched and unrivalled level of composure and balance, boosted further by the slack 63.5-degree head angle and proportional rear centres, that grow 14mm per-size, our industry-leading One Ride geometry also delivers a consistent ride experience across the size spectrum. Confident in the face of adversity, the Dreadnought is a bike quite unlike any other before it. Ziggy Link compatible, dual crown ready and open to interpretation, dream building a Dreadnought knows no bounds and neither does it.

HIGH PIVOT WITCHCRAFT

The most obvious feature of our Trifecta suspension system is the high pivot point and the resulting rearward axle path it produces. Unlike some other frame designs that talk of a rearward portion of their axle path, the height of our main pivot within the frame structure means our axle path takes a completely rearward trajectory throughout its travel. This rearward motion allows the rear wheel to move with, not against, any size of impact. This, in turn, allows the bike to remain composed and maintain momentum through rough terrain.

DREADNOUGHT GEOMETRY

170mm Fork		S	M	L	XL
A	Reach	440	462	484	506
B	Stack	612	621	630	639
C	Hori. Top Tube Length	593	617	641	665
D	Seat Tube Length	400	420	450	490
E	Seat Tube Angle (Effective)	76	76	76	76
F	Seat Tube Angle (Actual)	73.0	74.7	76.1	77.1
G	Head Tube Length	90	100	110	120
H	Head Tube Angle	63.5	63.5	63.5	63.5
I	Front Center	781	808	834	861
J	Rear Center	422	436	450	464
K	Wheel base	1203	1244	1284	1325
L	BB Drop	-26	-26	-26	-26
M	BB Height	347	347	347	347
N	Stand Over	721	721	727	733
O	Fork Length	583.71	583.71	583.71	583.71
P	Fork Offset	44	44	44	44
